تصویرسازی جریان

Flow Visualization describes the most widely used methods for visualizing flows. Flow visualization evaluates certain properties of a flow field directly accessible to visual perception. Organized into five chapters, this book first presents the methods that create a visible flow pattern that could be investigated by visual inspection, such as simple dye and density-sensitive visualization methods. It then deals with the application of electron beams and streaming birefringence. Optical methods for compressible flows, hydraulic analogy, and high-speed photography are discussed in other chapters. With appropriate flow pictures, this book tries to distinguish the various methods and the range of their applicability by outlining the physical principles on which each method is based. Content: Front Matter , Page iii Copyright , Page iv Preface , Pages vii-viii 1 - Introduction , Pages 1-4 2 - Addition of Foreign Materials into Gaseous and Liquid Fluid Flows , Pages 5-61 3 - Optical Methods for Compressible Flows , Pages 62-184 4 - Flow–Field Marking by Heat and Energy Addition , Pages 185-206 5 - Special Problems , Pages 207-229 Bibliography , Pages 230-244 Index , Pages 245-250
