International Building Code 2018

This code applies to all buildings except detached one- and two-family dwellings and townhouses up to three stories. The 2018 IBC contains many important changes such as: Accessory storage spaces of any size are now permitted to be classified as part of the occupancy to which they are accessory. New code sections have been introduced addressing medical gas systems and higher education laboratories. Use of fire walls to create separate buildings is now limited to only the determination of permissible types of construction based on allowable building area and height. Where an elevator hoistway door opens into a fire-resistance-rated corridor, the opening must be protected in a manner to address smoke intrusion into the hoistway. The occupant load factor for business uses has been revised to one occupant per 150 square feet. Live loads on decks and balconies increase the deck live load to one and one-half times the live load of the area served. The minimum lateral load that fire walls are required to resist is five pounds per square foot. Wind speed maps updated, including maps for the state of Hawaii. Terminology describing wind speeds has changed again with ultimate design wind speeds now called basic design wind speeds. Site soil coefficients now correspond to the newest generation of ground motion attenuation equations (seismic values). Five-foot tall wood trusses requiring permanent bracing must have a periodic special inspection to verify that the required bracing has been installed. New alternative fastener schedule for construction of mechanically laminated decking is added giving equivalent power-driven fasteners for the 20-penny nail. Solid sawn lumber header and girder spans for the exterior bearing walls reduce span lengths to allow #2 Southern Pine design values. 2018 IBC® INTERNATIONAL BUILDING CODE® 2018 IBC® TITLE PAGE COPYRIGHT PREFACE EFFECTIVE USE OF THE INTERNATIONAL BUILDING CODE TABLE OF CONTENTS CHAPTER 1 SCOPE AND ADMINISTRATION PART 1—SCOPE AND APPLICATION SECTION 101 GENERAL SECTION 102 APPLICABILITY PART 2—ADMINISTRATION AND ENFORCEMENT SECTION 103 DEPARTMENT OF BUILDING SAFETY SECTION 104 DUTIES AND POWERS OF BUILDING OFFICIAL SECTION 105 PERMITS SECTION 106 FLOOR AND ROOF DESIGN LOADS SECTION 107 SUBMITTAL DOCUMENTS SECTION 108 TEMPORARY STRUCTURES AND USES SECTION 109 FEES SECTION 110 INSPECTIONS SECTION 111 CERTIFICATE OF OCCUPANCY SECTION 112 SERVICE UTILITIES SECTION 113 BOARD OF APPEALS SECTION 114 VIOLATIONS SECTION 115 STOP WORK ORDER SECTION 116 UNSAFE STRUCTURES AND EQUIPMENT CHAPTER 2 DEFINITIONS SECTION 201 GENERAL SECTION 202 DEFINITIONS CHAPTER 3 OCCUPANCY CLASSIFICATION AND USE SECTION 301 SCOPE SECTION 302 OCCUPANCY CLASSIFICATION AND USE DESIGNATION SECTION 303 ASSEMBLY GROUP A SECTION 304 BUSINESS GROUP B SECTION 305 EDUCATIONAL GROUP E SECTION 306 FACTORY GROUP F SECTION 307 HIGH-HAZARD GROUP H TABLE 307.1(1) MAXIMUM ALLOWABLE QUANTITY PER CONTROL AREA OF HAZARDOUS MATERIALS POSING A PHYSICAL HAZARDa, j, m, n, p TABLE 307.1(1)—continued MAXIMUM ALLOWABLE QUANTITY PER CONTROL AREA OF HAZARDOUS MATERIALS POSING A PHYSICAL HAZARDa, j, m, n, p [F] TABLE 307.1(2) MAXIMUM ALLOWABLE QUANTITY PER CONTROL AREA OF HAZARDOUS MATERIALS POSING A HEALTH HAZARDa, c, f, h, i SECTION 308 INSTITUTIONAL GROUP I SECTION 309 MERCANTILE GROUP M SECTION 310 RESIDENTIAL GROUP R SECTION 311 STORAGE GROUP S SECTION 312 UTILITY AND MISCELLANEOUS GROUP U CHAPTER 4 SPECIAL DETAILED REQUIREMENTS BASED ON OCCUPANCY AND USE SECTION 401 SCOPE SECTION 402 COVERED MALL AND OPEN MALL BUILDINGS EQUATION 4-1 SECTION 403 HIGH-RISE BUILDINGS TABLE 403.2.4 MINIMUM BOND STRENGTH SECTION 404 ATRIUMS SECTION 405 UNDERGROUND BUILDINGS SECTION 406 MOTOR-VEHICLE-RELATED OCCUPANCIES TABLE 406.5.4 OPEN PARKING GARAGES AREA AND HEIGHT SECTION 407 GROUP I-2 SECTION 408 GROUP I-3 SECTION 409 MOTION PICTURE PROJECTION ROOMS SECTION 410 STAGES, PLATFORMS AND TECHNICAL PRODUCTION AREAS SECTION 411 SPECIAL AMUSEMENT BUILDINGS SECTION 412 AIRCRAFT-RELATED OCCUPANCIES TABLE 412.2.1.1 HEIGHT LIMITATIONS FOR AIRPORT TRAFFIC CONTROL TOWERS [F] TABLE 412.3.6 HANGAR FIRE SUPPRESSION REQUIREMENTSa, b, c TABLE 412.6 AIRCRAFT MANUFACTURING EXIT ACCESS TRAVEL DISTANCE SECTION 413 COMBUSTIBLE STORAGE SECTION 414 HAZARDOUS MATERIALS [F] TABLE 414.2.2 DESIGN AND NUMBER OF CONTROL AREAS [F] TABLE 414.2.5(1) MAXIMUM ALLOWABLE QUANTITY PER INDOOR AND OUTDOOR CONTROL AREA IN GROUP M AND S OCCUPANCIES NONFLAMMABLE SOLIDS AND NONFLAMMABLE AND NONCOMBUSTIBLE LIQUIDSd, e, f [F] TABLE 414.2.5(2) MAXIMUM ALLOWABLE QUANTITY OF FLAMMABLE AND COMBUSTIBLE LIQUIDS IN WHOLESALE AND RETAIL SALES OCCUPANCIES PER CONTROL AREAa [F] TABLE 414.5.1 EXPLOSION CONTROL REQUIREMENTSa, h SECTION 415 GROUPS H-1, H-2, H-3, H-4 AND H-5 [F] TABLE 415.6.2 DETACHED BUILDING REQUIRED [F] TABLE 415.11.1.1.1 QUANTITY LIMITS FOR HAZARDOUS MATERIALS IN A SINGLE FABRICATION AREA IN GROUP H-5a SECTION 416 SPRAY APPLICATION OF FLAMMABLE FINISHES SECTION 417 DRYING ROOMS SECTION 418 ORGANIC COATINGS SECTION 419 LIVE/WORK UNITS SECTION 420 GROUPS I-1, R-1, R-2, R-3 AND R-4 SECTION 421 HYDROGEN FUEL GAS ROOMS SECTION 422 AMBULATORY CARE FACIILITIES SECTION 423 STORM SHELTERS SECTION 424 CHILDREN’S PLAY STRUCTURES SECTION 425 HYPERBARIC FACILITIES SECTION [F] 426 COMBUSTIBLE DUSTS, GRAIN PROCESSING AND STORAGE SECTION 427 MEDICAL GAS SYSTEMS SECTION 428 HIGHER EDUCATION LABORATORIES [F] TABLE 428.3 DESIGN AND NUMBER OF LABORATORY SUITES PER FLOOR CHAPTER 5 GENERAL BUILDING HEIGHTS AND AREAS SECTION 501 GENERAL SECTION 502 BUILDING ADDRESS SECTION 503 GENERAL BUILDING HEIGHT AND AREA LIMITATIONS SECTION 504 BUILDING HEIGHT AND NUMBER OF STORIES TABLE 504.3 ALLOWABLE BUILDING HEIGHT IN FEET ABOVE GRADE PLANEa TABLE 504.4 ALLOWABLE NUMBER OF STORIES ABOVE GRADE PLANEa, b TABLE 504.4—continued ALLOWABLE NUMBER OF STORIES ABOVE GRADE PLANEa, b SECTION 505 MEZZANINES AND EQUIPMENT PLATFORMS SECTION 506 BUILDING AREA EQUATION 5-1 EQUATION 5-2 EQUATION 5-3 TABLE 506.2 ALLOWABLE AREA FACTOR (At = NS, S1, S13R, S13D or SM, as applicable) IN SQUARE FEETa, b TABLE 506.2—continued ALLOWABLE AREA FACTOR (At = NS, S1, S13R, S13D or SM, as applicable) IN SQUARE FEETa, b TABLE 506.2—continued ALLOWABLE AREA FACTOR (At = NS, S1, S13R, S13D or SM, as applicable) IN SQUARE FEETa, b EQUATION 5-4 EQUATION 5-5 SECTION 507 UNLIMITED AREA BUILDINGS SECTION 508 MIXED USE AND OCCUPANCY TABLE 508.4 REQUIRED SEPARATION OF OCCUPANCIES (HOURS)f SECTION 509 INCIDENTAL USES [F] TABLE 509 INCIDENTAL USES SECTION 510 SPECIAL PROVISIONS CHAPTER 6 TYPES OF CONSTRUCTION SECTION 601 GENERAL TABLE 601 FIRE-RESISTANCE RATING REQUIREMENTS FOR BUILDING ELEMENTS (HOURS) SECTION 602 CONSTRUCTION CLASSIFICATION TABLE 602 FIRE-RESISTANCE RATING REQUIREMENTS FOR EXTERIOR WALLS BASED ON FIRE SEPARATION DISTANCEa, d, g SECTION 603 COMBUSTIBLE MATERIAL IN TYPES I AND II CONSTRUCTION CHAPTER 7 FIRE AND SMOKE PROTECTION FEATURES SECTION 701 GENERAL SECTION 702 MULTIPLE USE FIRE ASSEMBLIES SECTION 703 FIRE-RESISTANCE RATINGS AND FIRE TESTS SECTION 704 FIRE-RESISTANCE RATING OF STRUCTURAL MEMBERS SECTION 705 EXTERIOR WALLS TABLE 705.2 MINIMUM DISTANCE OF PROJECTION EQUATION 7-1 EQUATION 7-2 FIGURE 705.7 EQUIVALENT OPENING FACTOR TABLE 705.8 MAXIMUM AREA OF EXTERIOR WALL OPENINGS BASED ON FIRE SEPARATION DISTANCE AND DEGREE OF OPENING PROTECTION SECTION 706 FIRE WALLS TABLE 706.4 FIRE WALL FIRE-RESISTANCE RATINGS SECTION 707 FIRE BARRIERS TABLE 707.3.10 FIRE-RESISTANCE RATING REQUIREMENTS FOR FIRE BARRIERS, FIRE WALLS OR HORIZONTAL ASSEMBLIES BETWEEN FIRE AREAS SECTION 708 FIRE PARTITIONS SECTION 709 SMOKE BARRIERS SECTION 710 SMOKE PARTITIONS SECTION 711 FLOOR AND ROOF ASSEMBLIES SECTION 712 VERTICAL OPENINGS SECTION 713 SHAFT ENCLOSURES SECTION 714 PENETRATIONS SECTION 715 FIRE-RESISTANT JOINT SYSTEMS SECTION 716 OPENING PROTECTIVES TABLE 716.1(1) MARKING FIRE-RATED GLAZING ASSEMBLIES TABLE 716.1(2) OPENING FIRE PROTECTION ASSEMBLIES, RATINGS AND MARKINGS TABLE 716.1(2)—continued OPENING FIRE PROTECTION ASSEMBLIES, RATINGS AND MARKINGS TABLE 716.1(3) FIRE WINDOW ASSEMBLY FIRE PROTECTION RATINGS SECTION 717 DUCTS AND AIR TRANSFER OPENINGS TABLE 717.3.2.1 FIRE DAMPER RATING SECTION 718 CONCEALED SPACES SECTION 719 FIRE-RESISTANCE REQUIREMENTS FOR PLASTER SECTION 720 THERMAL- AND SOUND-INSULATING MATERIALS SECTION 721 PRESCRIPTIVE FIRE RESISTANCE TABLE 721.1(1) MINIMUM PROTECTION OF STRUCTURAL PARTS BASED ON TIME PERIODS FOR VARIOUS NONCOMBUSTIBLE INSULATING MATERIALSm TABLE 721.1(1)—continued MINIMUM PROTECTION OF STRUCTURAL PARTS BASED ON TIME PERIODS FOR VARIOUS NONCOMBUSTIBLE INSULATING MATERIALSm TABLE 721.1(1)—continued MINIMUM PROTECTION OF STRUCTURAL PARTS BASED ON TIME PERIODS FOR VARIOUS NONCOMBUSTIBLE INSULATING MATERIALSm TABLE 721.1(1)—continued MINIMUM PROTECTION OF STRUCTURAL PARTS BASED ON TIME PERIODS FOR VARIOUS NONCOMBUSTIBLE INSULATING MATERIALSm TABLE 721.1(2) RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2)—continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2) —continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2)—continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2)—continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2)—continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2)—continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2)—continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, p TABLE 721.1(2)—continued RATED FIRE-RESISTANCE PERIODS FOR VARIOUS WALLS AND PARTITIONS a, o, TABLE 721.1(3) MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q TABLE 721.1(3)—continued MINIMUM PROTECTION FOR FLOOR AND ROOF SYSTEMSa, q SECTION 722 CALCULATED FIRE RESISTANCE TABLE 722.2.1.1 MINIMUM EQUIVALENT THICKNESS OF CAST-IN-PLACE OR PRECAST CONCRETE WALLS, LOAD-BEARING OR NONLOAD-BEARING EQUATION 7-3 EQUATION 7-4 FIGURE 722.2.1.3.1 CERAMIC FIBER JOINT PROTECTION FIGURE 722.2.1.2 FIRE-RESISTANCE RATINGS OF TWO-WYTHE CONCRETE WALLS TABLE 722.2.1.2(1) VALUES OF Rn0.59 FOR USE IN EQUATION 7-4 TABLE 722.2.1.2(2) FIRE-RESISTANCE RATINGS BASED ON R0.59 TABLE 722.2.1.4(1) MULTIPLYING FACTOR FOR FINISHES ON NONFIRE-EXPOSED SIDE OF WALL TABLE 722.2.1.4(2) TIME ASSIGNED TO FINISH MATERIALS ON FIRE-EXPOSED SIDE OF WALL TABLE 722.2.2.1 MINIMUM SLAB THICKNESS (inches) FIGURE 722.2.2.1.2 DETERMINATION OF SLAB THICKNESS FOR SLOPING SOFFITS EQUATION 7-5 FIGURE 722.2.2.1.3 SLABS WITH RIBBED OR UNDULATING SOFFITS FIGURE 722.2.2.2 FIRE-RESISTANCE RATINGS FOR TWO-COURSE CONCRETE FLOORS FIGURE 722.2.2.3(1) FIRE-RESISTANCE RATINGS FOR CONCRETE ROOF ASSEMBLIES FIGURE 722.2.2.3(2) FIRE-RESISTANCE RATINGS FOR CONCRETE ROOF ASSEMBLIES TABLE 722.2.3(1) COVER THICKNESS FOR REINFORCED CONCRETE FLOOR OR ROOF SLABS (inches) TABLE 722.2.3(2) COVER THICKNESS FOR PRESTRESSED CONCRETE FLOOR OR ROOF SLABS (inches) TABLE 722.2.3(3) MINIMUM COVER FOR MAIN REINFORCING BARS OF REINFORCED CONCRETE BEAMSc (APPLICABLE TO ALL TYPES OF STRUCTURAL CONCRETE) TABLE 722.2.3(4) MINIMUM COVER FOR PRESTRESSED CONCRETE BEAMS 8 INCHES OR GREATER IN WIDTHb TABLE 722.2.3(5) MINIMUM COVER FOR PRESTRESSED CONCRETE BEAMS OF ALL WIDTHS TABLE 722.2.4 MINIMUM DIMENSION OF CONCRETE COLUMNS (inches) TABLE 722.3.2 MINIMUM EQUIVALENT THICKNESS (inches) OF BEARING OR NONBEARING CONCRETE MASONRY WALLSa, b, c, d EQUATION 7-6 EQUATION 7-7 TABLE 722.3.4 MINIMUM COVER OF LONGITUDINAL REINFORCEMENT IN FIRE-RESISTANCE-RATED REINFORCED CONCRETE MASONRY LINTELS (inches) TABLE 722.3.5 MINIMUM DIMENSION OF CONCRETE MASONRY COLUMNS (inches) EQUATION 7-8 TABLE 722.4.1(1) FIRE-RESISTANCE PERIODS OF CLAY MASONRY WALLS TABLE 722.4.1(2) FIRE-RESISTANCE RATINGS FOR BEARING STEEL FRAME BRICK VENEER WALLS OR PARTITIONS EQUATION 7-9 TABLE 722.4.1(3) VALUES OF Rn 0.59 TABLE 722.4.1(4) COEFFICIENTS FOR PLASTER, pl a TABLE 722.4.1(5) REINFORCED MASONRY LINTELS TABLE 722.4.1(6) REINFORCED CLAY MASONRY COLUMNS EQUATION 7-10 EQUATION 7-11 FIGURE 722.5.1(1) DETERMINATION OF THE HEATED PERIMETER OF STRUCTURAL STEEL COLUMNS EQUATION 7-12 FIGURE 722.5.1(2) GYPSUM-PROTECTED STRUCTURAL STEEL COLUMNS WITH SHEET STEEL COLUMN COVERS FIGURE 722.5.1(3) GYPSUM-PROTECTED STRUCTURAL STEEL COLUMNS WITH STEEL STUD/SCREW ATTACHMENT SYSTEM FIGURE 722.5.1(4) FIRE RESISTANCE OF STRUCTURAL STEEL COLUMNS PROTECTED WITH VARIOUS THICKNESSES OF TYPE X GYPSUM WALLBOARD FIGURE 722.5.1(5) WIDE FLANGE STRUCTURAL STEEL COLUMNS WITH SPRAYED FIRE-RESISTANT MATERIALS FIGURE 722.5.1(6) CONCRETE PROTECTED STRUCTURAL STEEL COLUMNSa, b FIGURE 722.5.1(7) CONCRETE OR CLAY MASONRY PROTECTED STRUCTURAL STEEL COLUMNS EQUATION 7-13 EQUATION 7-14 EQUATION 7-15 EQUATOIN 7-16 FIGURE 722.5.2 DETERMINATION OF THE HEATED PERIMETER OF STRUCTURAL STEEL BEAMS AND GIRDERS EQUATION 7-17 TABLE 722.5.1(1) W/D RATIOS FOR STEEL COLUMNS TABLE 722.5.1(2) PROPERTIES OF CONCRETE TABLE 722.5.1(3) THERMAL CONDUCTIVITY OF CONCRETE OR CLAY MASONRY UNITS TABLE 722.5.1(4) WEIGHT-TO-HEATED-PERIMETER RATIOS (W/D) FOR TYPICAL WIDE FLANGE BEAM AND GIRDER SHAPES TABLE 722.5.1(4)—continued WEIGHT-TO-HEATED-PERIMETER RATIOS (W/D) FOR TYPICAL WIDE FLANGE BEAM AND GIRDER SHAPES TABLE 722.5.1(4)—continued WEIGHT-TO-HEATED-PERIMETER RATIOS (W/D) FOR TYPICAL WIDE FLANGE BEAM AND GIRDER SHAPES TABLE 722.5.1(5) FIRE RESISTANCE OF CONCRETE MASONRY PROTECTED STEEL COLUMNS TABLE 722.5.1(5)—continued FIRE RESISTANCE OF CONCRETE MASONRY PROTECTED STEEL COLUMNS TABLE 722.5.1(6) FIRE RESISTANCE OF CLAY MASONRY PROTECTED STEEL COLUMNS TABLE 722.5.1(7) MINIMUM COVER (inch) FOR STEEL COLUMNS ENCASED IN NORMAL-WEIGHT CONCRETEa [FIGURE 722.5.1(6)(c)] TABLE 722.5.1(8) MINIMUM COVER (inch) FOR STEEL COLUMNS ENCASED IN STRUCTURAL LIGHTWEIGHT CONCRETEa [FIGURE 722.5.1(6)(c)] TABLE 722.5.1(9) MINIMUM COVER (inch) FOR STEEL COLUMNS IN NORMAL-WEIGHT PRECAST COVERSa [FIGURE 722.5.1(6)(a)] TABLE 722.5.1(10) MINIMUM COVER (inch) FOR STEEL COLUMNS IN STRUCTURAL LIGHTWEIGHT PRECAST COVERSa [FIGURE 722.5.1(6)(a)] TABLE 722.6.2(1) TIME ASSIGNED TO WALLBOARD MEMBRANESa, b, c, d TABLE 722.6.2(2) TIME ASSIGNED FOR CONTRIBUTION OF WOOD FRAME a, b, c TABLE 722.6.2(3) MEMBRANEa ON EXTERIOR FACE OF WOOD STUD WALLS TABLE 722.6.2(4) FLOORING OR ROOFING OVER WOOD FRAMINGa TABLE 722.6.2(5) TIME ASSIGNED FOR ADDITIONAL PROTECTION CHAPTER 8 INTERIOR FINISHES SECTION 801 SCOPE SECTION 802 GENERAL SECTION 803 WALL AND CEILING FINISHES TABLE 803.13 INTERIOR WALL AND CEILING FINISH REQUIREMENTS BY OCCUPANCYk SECTION 804 INTERIOR FLOOR FINISH SECTION 805 COMBUSTIBLE MATERIALS IN TYPES I AND II CONSTRUCTION SECTION 806 DECORATIVE MATERIALS AND TRIM SECTION 807 INSULATION SECTION 808 ACOUSTICAL CEILING SYSTEMS CHAPTER 9 FIRE PROTECTION AND LIFE SAFETY SYSTEMS SECTION 901 GENERAL SECTION 902 FIRE PUMP AND RISER ROOM SIZE SECTION 903 AUTOMATIC SPRINKLER SYSTEMS [F] TABLE 903.2.5.2 GROUP H-5 SPRINKLER DESIGN CRITERIA [F] TABLE 903.2.11.6 ADDITIONAL REQUIRED SUPPRESSION SYSTEMS SECTION 904 ALTERNATIVE AUTOMATIC FIRE-EXTINGUISHING SYSTEMS SECTION 905 STANDPIPE SYSTEMS SECTION 906 PORTABLE FIRE EXTINGUISHERS [F] TABLE 906.1 ADDITIONAL REQUIRED PORTABLE FIRE EXTINGUISHERS IN THE INTERNATIONAL FIRE CODE [F] TABLE 906.3(1) FIRE EXTINGUISHERS FOR CLASS A FIRE HAZARDS [F] TABLE 906.3(2) FIRE EXTINGUISHERS FOR FLAMMABLE OR COMBUSTIBLE LIQUIDS WITH DEPTHS LESS THAN OR EQUAL TO 0.25 INCHa SECTION 907 FIRE ALARM AND DETECTION SYSTEMS [F] TABLE 907.5.2.3.2 VISIBLE ALARMS SECTION 908 EMERGENCY ALARM SYSTEMS SECTION 909 SMOKE CONTROL SYSTEMS EQUATION 9-1 EQUATION 9-2 SECTION 910 SMOKE AND HEAT REMOVAL EQUATION 9-3 EQUATION 9-4 SECTION 911 FIRE COMMAND CENTER SECTION 912 FIRE DEPARTMENT CONNECTIONS SECTION 913 FIRE PUMPS SECTION 914 EMERGENCY RESPONDER SAFETY FEATURES SECTION 915 CARBON MONOXIDE DETECTION SECTION 916 GAS DETECTION SYSTEMS SECTION 917 MASS NOTIFICATION SYSTEMS SECTION 918 EMERGENCY RESPONDER RADIO COVERAGE CHAPTER 10 MEANS OF EGRESS SECTION 1001 ADMINISTRATION [F] SECTION 1002 MAINTENANCE AND PLANS SECTION 1003 GENERAL MEANS OF EGRESS SECTION 1004 OCCUPANT LOAD TABLE 1004.5 MAXIMUM FLOOR AREA ALLOWANCES PER OCCUPANT SECTION 1005 MEANS OF EGRESS SIZING SECTION 1006 NUMBER OF EXITS AND EXIT ACCESS DOORWAYS TABLE 1006.2.1 SPACES WITH ONE EXIT OR EXIT ACCESS DOORWAY TABLE 1006.3.2 MINIMUM NUMBER OF EXITS OR ACCESS TO EXITS PER STORY TABLE 1006.3.3(1) STORIES WITH ONE EXIT OR ACCESS TO ONE EXIT FOR R-2 OCCUPANCIES TABLE 1006.3.3(2) STORIES WITH ONE EXIT OR ACCESS TO ONE EXIT FOR OTHER OCCUPANCIES SECTION 1007 EXIT AND EXIT ACCESS DOORWAY CONFIGURATION SECTION 1008 MEANS OF EGRESS ILLUMINATION SECTION 1009 ACCESSIBLE MEANS OF EGRESS SECTION 1010 DOORS, GATES AND TURNSTILES TABLE 1010.1.4.1(1) MAXIMUM DOOR SPEED MANUAL REVOLVING DOORS TABLE 1010.1.4.1(2) MAXIMUM DOOR SPEED AUTOMATIC OR POWER-OPERATED REVOLVING DOORS SECTION 1011 STAIRWAYS SECTION 1012 RAMPS SECTION 1013 EXIT SIGNS SECTION 1014 HANDRAILS SECTION 1015 GUARDS SECTION 1016 EXIT ACCESS SECTION 1017 EXIT ACCESS TRAVEL DISTANCE TABLE 1017.2 EXIT ACCESS TRAVEL DISTANCEa SECTION 1018 AISLES SECTION 1019 EXIT ACCESS STAIRWAYS AND RAMPS SECTION 1020 CORRIDORS TABLE 1020.1 CORRIDOR FIRE-RESISTANCE RATING TABLE 1020.2 MINIMUM CORRIDOR WIDTH SECTION 1021 EGRESS BALCONIES SECTION 1022 EXITS SECTION 1023 INTERIOR EXIT STAIRWAYS AND RAMPS SECTION 1024 EXIT PASSAGEWAYS SECTION 1025 LUMINOUS EGRESS PATH MARKINGS SECTION 1026 HORIZONTAL EXITS SECTION 1027 EXTERIOR EXIT STAIRWAYS AND RAMPS SECTION 1028 EXIT DISCHARGE SECTION 1029 ASSEMBLY TABLE 1029.6.2 CAPACITY FOR AISLES FOR SMOKE-PROTECTED ASSEMBLY TABLE 1029.13.2.1 SMOKE-PROTECTED OR OPEN-AIR ASSEMBLY AISLE ACCESSWAYS SECTION 1030 EMERGENCY ESCAPE AND RESCUE CHAPTER 11 ACCESSIBILITY SECTION 1101 GENERAL SECTION 1102 COMPLIANCE SECTION 1103 SCOPING REQUIREMENTS SECTION 1104 ACCESSIBLE ROUTE SECTION 1105 ACCESSIBLE ENTRANCES SECTION 1106 PARKING AND PASSENGER LOADING FACILITIES TABLE 1106.1 ACCESSIBLE PARKING SPACES SECTION 1107 DWELLING UNITS AND SLEEPING UNITS TABLE 1107.6.1.1 ACCESSIBLE DWELLING UNITS AND SLEEPING UNITS SECTION 1108 SPECIAL OCCUPANCIES TABLE 1108.2.2.1 ACCESSIBLE WHEELCHAIR SPACES TABLE 1108.2.7.1 RECEIVERS FOR ASSISTIVE LISTENING SYSTEMS TABLE 1108.3 ACCESSIBLE SELF-SERVICE STORAGE FACILITIES SECTION 1109 OTHER FEATURES AND FACILITIES TABLE 1109.12.2 ACCESSIBLE CHECK-OUT AISLES SECTION 1110 RECREATIONAL FACILITIES TABLE 1110.4.9.1 BOAT SLIPS SECTION 1111 SIGNAGE CHAPTER 12 INTERIOR ENVIRONMENT SECTION 1201 GENERAL SECTION 1202 VENTILATION TABLE 1202.3 INSULATION FOR CONDENSATION CONTROL SECTION 1203 TEMPERATURE CONTROL SECTION 1204 LIGHTING SECTION 1205 YARDS OR COURTS SECTION 1206 SOUND TRANSMISSION SECTION 1207 INTERIOR SPACE DIMENSIONS SECTION 1208 ACCESS TO UNOCCUPIED SPACES SECTION 1209 TOILET AND BATHROOM REQUIREMENTS CHAPTER 13 ENERGY EFFICIENCY SECTION 1301 GENERAL CHAPTER 14 EXTERIOR WALLS SECTION 1401 GENERAL SECTION 1402 PERFORMANCE REQUIREMENTS SECTION 1403 MATERIALS SECTION 1404 INSTALLATION OF WALL COVERINGS TABLE 1404.2 MINIMUM THICKNESS OF WEATHER COVERINGS TABLE 1404.3.2 CLASS III VAPOR RETARDERS SECTION 1405 COMBUSTIBLE MATERIALS ON THE EXTERIOR SIDE OF EXTERIOR WALLS TABLE 1405.1.1.1.2 MINIMUM FIRE SEPARATION FOR COMBUSTIBLE EXTERIOR WALL COVERINGS SECTION 1406 METAL COMPOSITE MATERIALS (MCM) TABLE 1406.11.3.4 AREA LIMITATION AND SEPARATION REQUIREMENTS FOR MCM PANELS SECTION 1407 EXTERIOR INSULATION AND FINISH SYSTEMS (EIFS) SECTION 1408 HIGH-PRESSURE DECORATIVE EXTERIOR-GRADE COMPACT LAMINATES (HPL) SECTION 1409 PLASTIC COMPOSITE DECKING CHAPTER 15 ROOF ASSEMBLIES AND ROOFTOP STRUCTURES SECTION 1501 GENERAL SECTION 1502 ROOF DRAINAGE SECTION 1503 WEATHER PROTECTION SECTION 1504 PERFORMANCE REQUIREMENTS TABLE 1504.1.1 CLASSIFICATION OF STEEP SLOPE ROOF SHINGLES TESTED IN ACCORDANCE WITH ASTM D316 OR D71581 TABLE 1504.8 MAXIMUM ALLOWABLE MEAN ROOF HEIGHT PERMITTED FOR BUILDINGS WITH AGGREGATE ON THE ROOF IN AREAS OUTSIDE A HURRICANE-PRONE REGION SECTION 1505 FIRE CLASSIFICATION TABLE 1505.1a, b MINIMUM ROOF COVERING CLASSIFICATION FOR TYPES OF CONSTRUCTION SECTION 1506 MATERIALS SECTION 1507 REQUIREMENTS FOR ROOF COVERINGS TABLE 1507.1.1(1) UNDERLAYMENT TYPES TABLE 1507.1.1(2) UNDERLAYMENT APPLICATION TABLE 1507.1.1(3) UNDERLAYMENT ATTACHMENT TABLE 1507.2.8.2 VALLEY LINING MATERIAL TABLE 1507.3.7 CLAY AND CONCRETE TILE ATTACHMENTa, b, c TABLE 1507.4.3(1) METAL ROOF COVERINGS TABLE 1507.4.3(2) MINIMUM CORROSION RESISTANCE TABLE 1507.7.6 SLATE SHINGLE HEADLAP TABLE 1507.8.5 WOOD SHINGLE MATERIAL REQUIREMENTS TABLE 1507.8.7 WOOD SHINGLE WEATHER EXPOSURE AND ROOF SLOPE TABLE 1507.8 WOOD SHINGLE AND SHAKE INSTALLATION TABLE 1507.9.6 WOOD SHAKE MATERIAL REQUIREMENTS TABLE 1507.9.8 WOOD SHAKE WEATHER EXPOSURE AND ROOF SLOPE TABLE 1507.10.2 BUILT-UP ROOFING MATERIAL STANDARDS TABLE 1507.14.3 PROTECTIVE COATING MATERIAL STANDARDS SECTION 1508 ROOF INSULATION [BF] TABLE 1508.2 MATERIAL STANDARDS FOR ROOF INSULATION SECTION 1509 RADIANT BARRIERS INSTALLED ABOVE DECK SECTION 1510 ROOFTOP STRUCTURES SECTION 1511 REROOFING SECTION 1512 PHOTOVOLTAIC PANELS AND MODULES CHAPTER 16 STRUCTURAL DESIGN SECTION 1601 GENERAL SECTION 1602 NOTATIONS SECTION 1603 CONSTRUCTION DOCUMENTS SECTION 1604 GENERAL DESIGN REQUIREMENTS TABLE 1604.3 DEFLECTION LIMITSa, b, c, h, i TABLE 1604.5 RISK CATEGORY OF BUILDINGS AND OTHER STRUCTURES SECTION 1605 LOAD COMBINATIONS EQUATION 16-1 EQUATION 16-2 EQUATION 16-3 EQUATION 16-4 EQUATION 16-5 EQUATION 16-6 EQUATION 16-7 EQUATION 16-8 EQUATION 16-9 EQUATION 16-10 EQUATION 16-11 EQUATION 16-12 EQUATION 16-13 EQUATION 16-14 EQUATION 16-15 EQUATION 16-16 EQUATION 16-17 EQUATION 16-18 EQUATION 16-19 EQUATION 16-20 EQUATION 16-21 EQUATION 16-22 SECTION 1606 DEAD LOADS SECTION 1607 LIVE LOADS TABLE 1607.1 MINIMUM UNIFORMLY DISTRIBUTED LIVE LOADS, L0, AND MINIMUM CONCENTRATED LIVE LOADSg TABLE 1607.1—continued MINIMUM UNIFORMLY DISTRIBUTED LIVE LOADS, L0, AND MINIMUM CONCENTRATED LIVE LOADSg TABLE 1607.1—continued MINIMUM UNIFORMLY DISTRIBUTED LIVE LOADS, L0, AND MINIMUM CONCENTRATED LIVE LOADSg TABLE 1607.1—continued MINIMUM UNIFORMLY DISTRIBUTED LIVE LOADS, Lo, AND MINIMUM CONCENTRATED LIVE LOADSg EQUATION 16-23 TABLE 1607.11.1 LIVE LOAD ELEMENT FACTOR, KLL EQUATION 16-24 EQUATION 16-25 EQUATION 16-26 EQUATION 16-27 EQUATION 16-28 EQUATION 16-29 EQUATION 16-30 EQUATION 16-31 EQUATION 16-32 SECTION 1608 SNOW LOADS TABLE 1608.2 GROUND SNOW LOADS, pg, FOR ALASKAN LOCATIONS FIGURE 1608.2 GROUND SNOW LOADS, pg, FOR THE UNITED STATES (psf) FIGURE 1608.2—continued GROUND SNOW LOADS, pg, FOR THE UNITED STATES (psf) SECTION 1609 WIND LOADS TABLE 1609.2 WINDBORNE DEBRIS PROTECTION FASTENING SCHEDULE FOR WOOD STRUCTURAL PANELSa, b, c, d EQUATION 16-33 TABLE 1609.3.1 WIND SPEED CONVERSIONSa, b, c FIGURE 1609.3(1) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY II BUILDINGS AND OTHER STRUCTURES FIGURE 1609.3(2) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY III BUILDINGS AND OTHER STRUCTURES FIGURE 1609.3(3) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY IV BUILDINGS AND OTHER STRUCTURES FIGURE 1609.3(4) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY I BUILDINGS AND OTHER STRUCTURES FIGURE 1609.3(5) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY II BUILDINGS AND OTHER STRUCTURES IN HAWAII FIGURE 1609.3(5)—continued BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY II BUILDINGS AND OTHER STRUCTURES IN HAWAII FIGURE 1609.3(6) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY III BUILDINGS AND OTHER STRUCTURES IN HAWAII FIGURE 1609.3(6)—continued BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY III BUILDINGS AND OTHER STRUCTURES IN HAWAII FIGURE 1609.3(7) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY IV BUILDINGS AND OTHER STRUCTURES IN HAWAII FIGURE 1609.3(7)—continued BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY IV BUILDINGS AND OTHER STRUCTURES IN HAWAII FIGURE 1609.3(8) BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY I BUILDINGS AND OTHER STRUCTURES IN HAWAII FIGURE 1609.3(8)—continued BASIC DESIGN WIND SPEEDS, V, FOR RISK CATEGORY I BUILDINGS AND OTHER STRUCTURES IN HAWAII EQUATION 16-34 SECTION 1610 SOIL LATERAL LOADS TABLE 1610.1 LATERAL SOIL LOAD SECTION 1611 RAIN LOADS EQUATION 16-35 [P] FIGURE 1611.1 100-YEAR, 1-HOUR RAINFALL (INCHES) WESTERN UNITED STATES [P] FIGURE 1611.1—continued 100-YEAR, 1-HOUR RAINFALL (INCHES) CENTRAL UNITED STATES [P] FIGURE 1611.1—continued 100-YEAR, 1-HOUR RAINFALL (INCHES) EASTERN UNITED STATES [P] FIGURE 1611.1—continued 100-YEAR, 1-HOUR RAINFALL (INCHES) ALASKA [P] FIGURE 1611.1—continued 100-YEAR, 1-HOUR RAINFALL (INCHES) HA SECTION 1612 FLOOD LOADS SECTION 1613 EARTHQUAKE LOADS EQUATON 16-36 EQUATOIN 16-37 EQUATION 16-38 EQUATION 16-39 TABLE 1613.2.3(1) VALUES OF SITE COEFFICIENT Fa a TABLE 1613.2.3(2) VALUES OF SITE COEFFICIENT FV a TABLE 1613.2.5(1) SEISMIC DESIGN CATEGORY BASED ON SHORT-PERIOD (0.2 second) RESPONSE ACCELERATION TABLE 1613.2.5(2) SEISMIC DESIGN CATEGORY BASED ON 1-SECOND PERIOD RESPONSE ACCELERATION FIGURE 1613.2.1(1) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR THE CONTERMINOUS UNITED STATES OF 0.2-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(1)—continued RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR THE CONTERMINOUS UNITED STATES OF 0.2-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(2) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR THE CONTERMINOUS UNITED STATES OF 1-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(2)—continued RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR THE CONTERMINOUS UNITED STATES OF 1-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(3) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR HAWAII OF 0.2- AND 1-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(4) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR ALASKA OF 0.2-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(5) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR ALASKA OF 1.0-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(6) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR PUERTO RICO AND THE UNITED STATES VIRGIN ISLANDS OF 0.2- AND 1-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(7) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR GUAM AND THE NORTHERN MARIANA ISLANDS OF 0.2- AND 1-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) FIGURE 1613.2.1(8) RISK-TARGETED MAXIMUM CONSIDERED EARTHQUAKE (MCER) GROUND MOTION RESPONSE ACCELERATIONS FOR AMERICAN SAMOA OF 0.2- AND 1-SECOND SPECTRAL RESPONSE ACCELERATION (5% OF CRITICAL DAMPING) SECTION 1614 ATMOSPHERIC ICE LOADS SECTION 1615 TSUNAMI LOADS SECTION 1616 STRUCTURAL INTEGRITY EQUATION 16-40 EQUATION 16-41 FIGURE 1616.3 LONGITUDINAL, PERIMETER, TRANSVERSE AND VERTICAL TIES CHAPTER 17 SPECIAL INSPECTIONS AND TESTS SECTION 1701 GENERAL SECTION 1702 NEW MATERIALS SECTION 1703 APPROVALS SECTION 1704 SPECIAL INSPECTIONS AND TESTS, CONTRACTOR RESPONSIBILITY AND STRUCTURAL OBSERVATION SECTION 1705 REQUIRED SPECIAL INSPECTIONS AND TESTS TABLE 1705.2.3 REQUIRED SPECIAL INSPECTIONS OF OPEN-WEB STEEL JOISTS AND JOIST GIRDERS TABLE 1705.3 REQUIRED SPECIAL INSPECTIONS AND TESTS OF CONCRETE CONSTRUCTION TABLE 1705.6 REQUIRED SPECIAL INSPECTIONS AND TESTS OF SOILS TABLE 1705.7 REQUIRED SPECIAL INSPECTIONS AND TESTS OF DRIVEN DEEP FOUNDATION ELEMENTS TABLE 1705.8 REQUIRED SPECIAL INSPECTIONS AND TESTS OF CAST-IN-PLACE DEEP FOUNDATION ELEMENTS SECTION 1706 DESIGN STRENGTHS OF MATERIALS SECTION 1707 ALTERNATIVE TEST PROCEDURE SECTION 1708 IN-SITU LOAD TESTS SECTION 1709 PRECONSTRUCTION LOAD TESTS CHAPTER 18 SOILS AND FOUNDATIONS SECTION 1801 GENERAL SECTION 1802 DESIGN BASIS SECTION 1803 GEOTECHNICAL INVESTIGATIONS SECTION 1804 EXCAVATION, GRADING AND FILL SECTION 1805 DAMPPROOFING AND WATERPROOFING SECTION 1806 PRESUMPTIVE LOAD-BEARING VALUES OF SOILS TABLE 1806.2 PRESUMPTIVE LOAD-BEARING VALUES SECTION 1807 FOUNDATION WALLS, RETAINING WALLS AND EMBEDDED POSTS AND POLES TABLE 1807.1.6.2 CONCRETE FOUNDATION WALLSb, c TABLE 1807.1.6.3(1) PLAIN MASONRY FOUNDATION WALLSa, b, c EQUATION 18-1 尰〰呜〰ぁ尰〰䉜〰が尰〰䕜〰〠尰〰ᅮ〰十尰〰ぜ〰〷尰〰⹜〰〱尰〰⹜〰〒尰〰⹜〰〳尰〰⡜〰〲尰〰⥜〰〠尰〰㡜〰〭尰〰䥜〰ぎ尰〰䍜〰え尰〰⁜〰き尰〰䅜〰こ尰〰作〰ぎ尰〰剜〰す尰〰⁜〰う尰〰作〰さ尰〰乜〰い尰〰䅜〰ご尰〰䥜〰く尰〰乜〰〠尰〰坜〰ぁ尰〰䱜〰が尰〰卜〰〠尰〰坜〰ぉ尰〰呜〰え尰〰⁜〰げ尰〰䕜〰ぉ尰〰乜〰う尰〰作〰げ尰〰䍜〰ぅ尰〰䵜〰ぅ尰〰乜〰ご尰〰⁜〰し尰〰䡜〰ぅ尰〰剜〰ぅ尰〰⁜〰つ尰〰•敜〰〠尰〰㕜〰〠尰〰䥜〰ぎ尰〰䍜〰え尰〰䕜〰こ尰〰慜〰〬尰〰⁜〰ぢ尰〰ⱜ〰〠尰〰挀 EQUATION 18-2 EQUATION 18-3 尰〰呜〰ぁ尰〰䉜〰が尰〰䕜〰〠尰〰ᅮ〰十尰〰ぜ〰〷尰〰⹜〰〱尰〰⹜〰〒尰〰⹜〰〳尰〰⡜〰〳尰〰⥜〰〠尰〰ᅮ〰〰尰〰ⵜ〰ぉ尰〰乜〰ぃ尰〰䡜〰〠尰〰䵜〰ぁ尰〰卜〰く尰〰乜〰げ尰〰奜〰〠尰〰䙜〰く尰〰啜〰ぎ尰〰䑜〰ぁ尰〰呜〰ぉ尰〰作〰ぎ尰〰⁜〰し尰〰䅜〰が尰〰䱜〰こ尰〰⁜〰し尰〰䥜〰ご尰〰䡜〰〠尰〰剜〰ぅ尰〰䥜〰ぎ尰〰䙜〰く尰〰剜〰ぃ尰〰䕜〰き尰〰䕜〰ぎ尰〰呜〰〠尰〰坜〰え尰〰䕜〰げ尰〰䕜〰〠尰〰摜〰〠≥尰〰⁜〰〒尰〰⹜〰〷尰〰㕜〰〠尰〰䥜〰ぎ尰〰䍜〰え尰〰䕜〰こ尰〰⁜〰ち尰〰ⱜ〰〠尰〰扜〰〬尰〰⁜〰っ 尰〰呜〰ぁ尰〰䉜〰が尰〰䕜〰〠尰〰ᅮ〰十尰〰ぜ〰〷尰〰⹜〰〱尰〰⹜〰〒尰〰⹜〰〳尰〰⡜〰〴尰〰⥜〰〠尰〰ᅮ〰〲尰〰ⵜ〰ぉ尰〰乜〰ぃ尰〰䡜〰〠尰〰䵜〰ぁ尰〰卜〰く尰〰乜〰げ尰〰奜〰〠尰〰䙜〰く尰〰啜〰ぎ尰〰䑜〰ぁ尰〰呜〰ぉ尰〰作〰ぎ尰〰⁜〰し尰〰䅜〰が尰〰䱜〰こ尰〰⁜〰し尰〰䥜〰ご尰〰䡜〰〠尰〰剜〰ぅ尰〰䥜〰ぎ尰〰䙜〰く尰〰剜〰ぃ尰〰䕜〰き尰〰䕜〰ぎ尰〰呜〰〠尰〰坜〰え尰〰䕜〰げ尰〰䕜〰〠尰〰摜〰〠≥尰〰⁜〰十尰〰⹜〰〷尰〰㕜〰〠尰〰䥜〰ぎ尰〰䍜〰え尰〰䕜〰こ尰〰慜〰〬尰〰⁜〰ぢ尰〰ⱜ〰〠尰〰挀 SECTION 1808 FOUNDATIONS FIGURE 1808.7.1 FOUNDATION CLEARANCES FROM SLOPES TABLE 1808.8.1 MINIMUM SPECIFIED COMPRESSIVE STRENGTH f ́ C OF CONCRETE OR GROUT TABLE 1808.8.2 MINIMUM CONCRETE COVER SECTION 1809 SHALLOW FOUNDATIONS TABLE 1809.7 PRESCRIPTIVE FOOTINGS SUPPORTING WALLS OF LIGHT-FRAME CONSTRUCTIONa, b, c, d, e SECTION 1810 DEEP FOUNDATIONS TABLE 1810.3.2.6 ALLOWABLE STRESSES FOR MATERIALS USED IN DEEP FOUNDATION ELEMENTS EQUATION 18-4 EQUATION 18-5 EQUATION 18-6 EQUATION 18-7 EQUATION 18-8 EQUATION 18-9 EQUATION 18-10 CHAPTER 19 CONCRETE SECTION 1901 GENERAL SECTION 1902 DEFINITIONS SECTION 1903 SPECIFICATIONS FOR TESTS AND MATERIALS SECTION 1904 DURABILITY REQUIREMENTS SECTION 1905 MODIFICATIONS TO ACI 318 SECTION 1906 STRUCTURAL PLAIN CONCRETE SECTION 1907 MINIMUM SLAB PROVISIONS SECTION 1908 SHOTCRETE CHAPTER 20 ALUMINUM SECTION 2001 GENERAL SECTION 2002 MATERIALS CHAPTER 21 MASONRY SECTION 2101 GENERAL SECTION 2102 NOTATIONS SECTION 2103 MASONRY CONSTRUCTION MATERIALS TABLE 2103.2.3 CERAMIC TILE MORTAR COMPOSITIONS SECTION 2104 CONSTRUCTION SECTION 2105 QUALITY ASSURANCE SECTION 2106 SEISMIC DESIGN SECTION 2107 ALLOWABLE STRESS DESIGN EQUATION 21-1 SECTION 2108 STRENGTH DESIGN OF MASONRY SECTION 2109 EMPIRICAL DESIGN OF ADOBE MASONRY EQUATION 21-2 TABLE 2109.2.3.1 ALLOWABLE SHEAR ON BOLTS IN ADOBE MASONRY SECTION 2110 GLASS UNIT MASONRY SECTION 2111 MASONRY FIREPLACES FIGURE 2111.12 ILLUSTRATION OF EXCEPTION TO FIREPLACE CLEARANCE PROVISION SECTION 2112 MASONRY HEATERS SECTION 2113 MASONRY CHIMNEYS FIGURE 2113.16 FLUE SIZES FOR MASONRY CHIMNEYS TABLE 2113.16(1) NET CROSS-SECTIONAL
