مرجع اصلی منطق IC [منبع الکترونیکی]

Logic IC Master Reference summarizes the identification codes, functions, pinouts, and package styles for a broad range of digital IC devices. The main body of this book is divided into three sections: Section I - 54/7400 TTL and CMOS devices; Section II - 4000-series CMOS devices; Section III - ECL devices. The selections regarding functions are generally limited to small- and medium-scale devices, logic functions, buffers, decoders, multiplexers, counters, and shift registers. A few large-scale digital devices and devices provided by two or more major IC manufacturers are included. The two indexes are organized by device identification code and by device function. This reference text will prove useful to digital design engineers and technicians. Content: Front Matter , Page iii Copyright , Page iv Preface , Page vii 54/7400-Series Devices , Pages 2-569 4000-Series CMOS Devices , Pages 571,573-618 10000-Series ECL Devices , Pages 620-705 Device Identification Code Index , Pages 707-723 Device Function Index , Pages 725-735 Errata , Page ibc1
